PH 15-7 Mo Stainless Steel
Introduction
Overview of PH 15-7 Mo Stainless Steel
Grade PH 15-7 Mo stainless steel, also known as UNS S15700 staonless steel. It comes from the chemical compositions of chromium (15.0%), nickel (7.0%), molybdenum (2.0%), and aluminum (1.10%).
It is a semi-austenitic precipitation hardening steel that provides high strength and hardness, good corrosion resistance, and minimum distortion upon heat treatment.
PH 15-7 Mo exhibits better corrosion resistance than 17-4 PH stainless steel in most environments. PH 15-7 Mo is magnetic in both the annealed and hardened conditions.
PH 15-7 Mo material is used for parts requiring high strength, moderate corrosion resistance where a combination of high mechanical strength with good ductility is required after heat treatment.
Features of PH 15-7 Mo Stainless Steel
- High strength and hardness
- Good corrosion resistance
- Minimum distortion on heat treatment
PH 15-7 Mo Stainless Steel Applications
- Aircraft structural parts
- Aircraft interior parts
- Aerospace components
- Medical instruments and implants
- Food processing equipment
- Food handling conveyor belts and chains
- Jewelry and watches
Quality Products
Technical Data
| PH 15-7 Mo Stainless Steel Standards Comparison Table | ||||||||
| STS | USA | UNS | CHINA | EURONORM | RUSSIA | SWEDISH | JAPANESE | |
| GRADE | AISI/ASTM | NO | GB | NO | NAME | GOST | SS | JIS |
| PH 15-7 Mo | 632 | S15700 | – | 1.4574 | – | – | – | – |
| Chemical Composition | |||||||||
| Element | C | Mn | Si | P | S | Cr | Ni | Mo | Al |
| PH 15-7 Mo/UNS S15700 | 0.09 | 1.00 | 1.00 | 0.04 | 0.03 | 14-16 | 6.50-7.75 | 2-3 | 0.75-1.5 |
| Grade | Condition | Thickness (inch) | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation % | Hardness |
| PH 15-7 Mo/UNS S15700 | Solution Treated | <0.005 | 150 (max) | 65 (max) | 25 | 100 HB (max) |
| PH 15-7 Mo/UNS S15700 | TH1050 (AMS 5520) | 0.010-0.020 | 190 | 170 | 4 | 40 HRC |
| PH 15-7 Mo/UNS S15700 | TH1050 (AMS 5520) | 0.020-0.1875 | 190 | 170 | 5 | 40 HRC |
| PH 15-7 Mo/UNS S15700 | TH1050 (AMS 5520) | 0.1875-0.500 | 190 | 170 | 6 | 40 HRC |
| PH 15-7 Mo/UNS S15700 | RH950 (AMS 5520) | 0.010-0.020 | 225 | 220 | 3 | 45 HRC |
| PH 15-7 Mo/UNS S15700 | RH950 (AMS 5520) | 0.020-0.1875 | 225 | 220 | 4 | 45 HRC |
| PH 15-7 Mo/UNS S15700 | RH950 (AMS 5520) | 0.1875-0.500 | 225 | 220 | 5 | 45 HRC |
| PH 15-7 Mo/UNS S15700 | Condition C | – | 200 | 175 | 1 | 41 HRC |
| PH 15-7 Mo/UNS S15700 | Condition CH900 | – | 240 | 230 | 1 | 46 HRC |
