347 Stainless Steel
Introduction
Overview of 347 Stainless Steel
347 stainless steel is an austenitic low-alloyed steel that has a minimum strength of 100 ksi (690 MPa) and a maximum carbon content of 0.15%. Its tensile strength can be increased by cold working it.
347 stainless steel is similar to 302 and 303, but has a higher carbon content and greater strength and hardness at elevated temperatures. It is used for high temperature applications such as heat exchanger tubing and boiling water heaters.
Futures of 347 Stainless Steel
The following are some of the more common features of 347 stainless steel:
- Highly resistant to corrosion in marine environments
- Good oxidation resistance in general service conditions
- Excellent strength at elevated temperatures
- Good impact toughness at room temperature
347 Stainless Steel Applications
- Chemical Industry
- Food Equipment
- Petroleum Industry
- Pharmaceutical Production Line
- Waste Heat Recovery Industry
- Heat Exchange Industry
347 Stainless Steel Tags
- Grade 347
- Type 347
- Inox 347
- AISI 347
- SUS 347
- 1.4550
- UNS S34709
Quality Products
Technical Data
| 347 Stainless Steel Standards Comparison Table | ||||||||
| STS | USA | UNS | CHINA | EURONORM | RUSSIA | SWEDISH | JAPANESE | |
| GRADE | AISI/ASTM | NO | GB | NO | NAME | GOST | SS | JIS |
| 347 | 347 | S34709 | 06Cr18Ni9 | 1.4550 | X 6 CrNiNb 18 10 | – | 2338 | SUS 347 |
| Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Mo |
| 347 | ASTM A240 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 17.00-19.00 | 9.00-13.00 | – |
| Grade | EN Grade | Yield Strength Rp0.2(N/mm²) | Tensile Strength Rm(N/mm²) | Hardness | Vickers Hardness(HV) | Elongation A50% |
| 347 | 1.4550 | ≥205 | ≥520 | Annealed | ≥150 | ≥40 |
